    Character LCD 2.4" 16x4, B/L yellow/green, STN yellow/green pos, Transflective, COB, 3.3V, Interface 6800, Font Eng/Eu, 6 O'clock
    Brand: Winstar
    Cod.: WH1604B-YYH-ETV#

    Kit accessori

    Prezzi per quantità
    Quantità
    1+
    5+
    10+
    25+
    Prezzo
    €14,70
    €13,30
    €12,50
    €12,20

    Per quantità maggiori di 49pz prego invii la richiesta a [email protected] o chiami il +39 0332 1888005

    Disponibilità: Disponibile
    €14,70 IVA esclusa
    i h



    DRAWING

    Specifiche di prodotto
    Size 2.4"
    Resolution 16x4
    Active Area (mm) 56.20x20.80
    Dot Size 0.55x0.55
    B/L color, LCD type B/L yellow/green, STN yellow/green pos
    Power supply 3.3V
    Display Interface 6800
    Display IC ST7066
    Constructive Structure COB
    View Angle 6H
    O. Temperature (°C) -20~70
    Data Connection Soldering PAD
    Pin Nr. 16
    Pin Pitch 2.54mm
    Preferred - Not Preferred Preferred
    *
    *
    *
    *
