COG OLED Families with PCB for Easy Assembly!

COG OLED Families with PCB for Easy Assembly!

WINSTAR



2.23" Graphic 128x32 OLED with Capacitive Touch + PCB

WEP12832x#A8D-FC Graphic COG OLED 2.23'' 128x32 with capacitive touch panel and PCB with mounting holes for an easy fixing on customers' chassis. The module is built in with SSD1305 IC; it supports 6800/8080 8-bit parallel, I2C, and 4-Wire SPI interfaces. Capacitive touch panel I2C interface, FT6336U IC, one finger detect point, glare surface. Supply voltage for logic 3.3V: 50% check board current 85mA @3.3VDD (typical value), driving duty 1/32. Two fixing methods: mounting holes or strip connector pins 2.45mm pitch (soldering PAD or FPC connection on request). Mini vibration motor and buzzer optional as well. Operating temperature from -20℃ to +70℃; storage temperature from -40℃ to +85℃.

Product Specifications:

  • Size: 2.23''
  • Dot matrix: 128 x 32 pixels
  • Module dimension: 66.5x35x10.55 mm
  • Active area: 55.018x13.098 mm
  • Pixel size: 0.408x0.388 mm
  • Display color: white / yellow / blue
  • Drive duty: 1/32
  • OLED IC: SSD1305
  • OLED interface: 6800-8080, SPI, I2C
  • CTP IC: FT6336U
  • Detect point: 1
  • CTP interface: I2C





1.50" Graphic 128x128 Square Shape OLED + PCB

WEA128128x#A00-FC Graphic square COG OLED 1.50'' 128x128 with PCB mounting holes for an easy fixing on customers' chassis. The module is built in with SSD1327 IC; it supports 4-wire SPI interface (optional I2C interface). Supply voltage for logic is from 3.3V (optional 5V): 50% check board current 160mA @3.3VDD (typical value), driving duty 1/128, 16 gray scale (4 bits). Two fixing methods: mounting holes or strip connector pins 2.54mm pitch. Operating temperature from -40℃ to +80℃; storage temperature from -40℃ to +85℃.

Product Specifications:

  • Size: 1.50''
  • Dot matrix:128x128 pixels
  • Module dimension: 34.2x45.5x3.16 mm
  • Active area: 26.86x26.86 mm
  • Pixel size: 0.185x0.185 mm
  • Pixel pitch: 0.210x0.210 mm
  • Display mode: passive matrix
  • Display color: white / yellow / sky blue
  • Drive duty: 1/128
  • Gray scale: 4 bits
  • IC: SSD1327
  • Interface: 4-wire SPI (I2C optional)


2.93'' Character 20x2 OLED + PCB

WEP2002x#A00-FC Character COG OLED 2.93'' 20x2 with PCB mounting holes for an easy fixing on customers' chassis. The module is built in with SSD1311 IC; it supports 6800/8080 4bit/8bit parallel, I2C, and 4-Wire SPI interfaces. This model has ROMs for ASCII, English, European and Japanese characters. The modules have integrated interface setting and VCC circuit which allow customers simple use without developing any extra PCB. Supply voltage for logic is default 3.3V (optional 5V): display with 50% check board current 50mA @ 3.3VDD, driving duty 1/16. Operating temperature from -40℃ to +80℃; storage temperature from -40℃ to +85℃.

Product Specifications:

  • Size: 2.93''
  • Number of characters: 20 ch.x2 lines
  • Module dimension: 92.3x23.3x7 mm
  • Active area: 73.52x11.52 mm
  • Dot size: 0.62x0.67 mm
  • Character size: 3.22x5.57 mm
  • Character pitch: 3.70x5.95 mm
  • Display color: white / yellow
  • Duty: 1/16
  • IC: SSD1311
  • Interface: 6800-8080, SPI, I2C







;
