HDMI Interface TFTs from 4.3'' to 15.6'', Standard-Wide View Angle (IPS), Standard-High Brightness

Friday, October 2, 2020




HDMI TFT LCD Modules:



  • > Sizes: 4.3''/ 5''/ 7''/ 8''/ 9''/ 10.3''/ 13.3''/ 15.6''
  • > Resolutions: from 800x480pixels to 1920x1080pixels
  • > Viewing Angle: Standard / Wide View Angle (IPS) up to 85°/85°/85°/85°
  • > Brightness: from 200cd/m² to 1200cd/m²
  • > Touch panel: No / PCAP I2C interface / PCAP USB interface

Below please find some last products introduction:

  •



    Product 4.3'' HDMI TFT LCD Module



    VGG804830-series is a 4.3 inches TFT LCD module with 800RGBx480 resolution. The outline size of the module is 125.5(W)*67.2(H)*8.15(D) mm. VGG804830-series supports HDMI* interface, driven by 4.5~5.5 V(11.5~12.0V) . Assembled to the TFT display, our PCB provides the user an all-in-one, HDMI* interface, LED driver and USB/I2C Touch solution for virtually any application.

    *Support HDMI interface, suit for your digital device.



    ☛ VGG804830-B (No-touch)

    ☛ VGG804830-C (with PCAP Touch(USB)).













    Product 5'' HDMI TFT LCD Module



    VGG804830-series is a 5.0 inches TFT LCD module with 800RGBx480 resolution. The outline size of the module is 118.5(W)*77.55(H)*3.4(D) mm. VGG804830-series supports HDMI* interface, driven by 4.5~5.5 V . Assembled to the TFT display, our PCB provides the user an all-in-one, HDMI* interface, LED driver and USB/I2C Touch solution for virtually any application.

    *Support HDMI interface, suit for your digital device.



    ☛ VGG804826-A (No-touch)

    ☛ VGG804826-D (with PCAP Touch(USB)).

    ☛  VGG804826-E (with PCAP Touch(I2C)).











    Product 7'' HDMI TFT LCD Module



    VGG804824-series is a 7.0 inches TFT LCD module with 800RGBx480 resolution. The outline size of the module is 166.6(W)*109.4(H)*10. 0(D) mm. VGG804824-series supports HDMI* interface, driven by 4.5~5.5V . Assembled to the TFT display, our PCB provides the user an all-in-one, HDMI* interface, LED driver and USB/I2C Touch solution for virtually any application.

    *Support HDMI interface, suit for your digital device.



    ☛ VGG804824-A (No-touch)

    ☛ VGG804824-B (with PCAP Touch(USB)).









     For more information, please send an email to info@first-components.com










;
