The 10.25" Bar format provides designers with an elongated viewing area for developing HMI interfaces with high information density while keeping module dimensions under control.
The WFN1025LA2#0SPW15-FC is a TFT LCD with a resolution of 1920 × 720 pixels, IPS technology and a typical brightness of 800 cd/m². It integrates a 10-point PCAP capacitive touch panel and optical bonding with OCA adhesive, combining display and touch functionality in a single module.
The 243.65 × 91.37 mm active area and elongated format allow designers to develop the graphical layout around the product's geometry and the information that needs to be accessible to the operator.
A Module Designed for Industrial HMIs
IPS technology provides a viewing angle of 85° in all directions, maintaining good image uniformity even when the display is viewed from positions that are not directly in front of the screen. The typical brightness of 800 cd/m² also helps maintain interface readability in environments with varying lighting conditions.
The PCAP capacitive touch panel supports up to 10-point multi-touch, while optical bonding with OCA adhesive eliminates internal reflections between the display and touch panel. This improves optical coupling within the module and contributes to better image readability.
The display and touch panel share a single connector to the host system, integrating both the video and capacitive touch signals. This simplifies cabling and module integration into the HMI.
Designed for applications that do not always operate under ideal conditions, the module supports an extended operating temperature range from −30°C to +85°C. This is particularly relevant for HMIs and industrial equipment installed in environments subject to significant temperature variations, where display operating continuity is an integral part of overall system reliability.
Key Specifications
| Parameter | Specification |
|---|---|
| Active Area | 243.65 × 91.37 mm |
| Module Dimensions | 277.5 × 127.0 × 12.95 mm |
| Display Technology | IPS |
| Viewing Angle | 85° / 85° / 85° / 85° |
| Display Interface | 1-port LVDS (VESA) |
| Touch Panel | PCAP, I²C interface, GT9271 controller |
| Optical Bonding | OCA adhesive |
The WFN1025LA2#0SPW15-FC integrates PCAP capacitive touch for applications requiring direct interaction with the interface. For projects that do not require touch functionality, the WFN1025LA2#0SPW0-FC version is also available.
Considering This Display for a New Project?
Samples and evaluation kits are available for technical evaluation and prototyping.
The FIRST Components team can support you in verifying the specifications, interfaces and integration requirements for your system.
