RYLR896

Frequency Range:868 / 915 MHz, Control by AT command, 42.5*18.36*5.5 mm
  • Application: Iot Applications, Mobile Equipment, Home Security, Industrial Monitoring and Control Equipment, Car Alarm.
  • Certification: NCC, FCC
  • Frequency Range:868/915 MHz
  • Semtech SX1276 Engine
  • High efficiency Power Amplifier
  • Excellent blocking immunity
  • Low Receive current
  • High sensitivity
  • Control easily by AT commands
  • 127 dB Dynamic Range RSSI
  • Designed with integrated antenna
  • AES128 Data encryption
  • Operation temperature: -40℃ to +85℃
  • Dimension: 42.5*18.36*5.5 mm
  • Weight: 7g

The RYLR896 transceiver module feature the Lora long range modem that provides ultra-long range spread spectrum communication and high interference immunity whilst minimising current consumption. The module is certified by NCC and FCC.



Item Min. Typical Max. Unit Condition
VDD Power Supply 2 3.3 3.6 V VDD
RF Output Power Range -4   15 dBm
Filter insertion loss 1 2 3 dB
RF Sensitivity -148     dBm
RF Input Level     10 dBm
Frequency Range 862 868/915 1020 MHz
Frequency Accuracy   ±2   ppm
Communication Range   4.5 15 KM Depend on RF parameter
Transmit Current   43   mA RFOP = +15 dBm
Receive Current   16.5   mA AT+MODE=0
Sleep Current   0.5   uA AT+MODE=1
Baud rate 300 115200 115200 bps 8, N, 1
Digital Input Level High 0.7*VDD   VDD V VIH
Digital Input Level Low 0   0.3*VDD V VIL
Digital Output Level High 0.9   VDD V VOH
Digital Output Level Low     0.1 V VOL
Cycling (erase / write)



EEPROM data memory

   300   K Cycles
Weight   7   g
Operating Temperature -40 25 +85 ˚C
SKU: RYLR896
Brand: Reyax
Available: Yes
Be the first to review this product
Price Breaks
Quantity
1+
5+
Price
€10.30
€10.00

For quantities above 25 pcs pls send your enquiry to sales@first-components.com or call +39 0332 1888005

€10.30 excl tax
  • Application: Iot Applications, Mobile Equipment, Home Security, Industrial Monitoring and Control Equipment, Car Alarm.
  • Certification: NCC, FCC
  • Frequency Range:868/915 MHz
  • Semtech SX1276 Engine
  • High efficiency Power Amplifier
  • Excellent blocking immunity
  • Low Receive current
  • High sensitivity
  • Control easily by AT commands
  • 127 dB Dynamic Range RSSI
  • Designed with integrated antenna
  • AES128 Data encryption
  • Operation temperature: -40℃ to +85℃
  • Dimension: 42.5*18.36*5.5 mm
  • Weight: 7g

The RYLR896 transceiver module feature the Lora long range modem that provides ultra-long range spread spectrum communication and high interference immunity whilst minimising current consumption. The module is certified by NCC and FCC.



Item Min. Typical Max. Unit Condition
VDD Power Supply 2 3.3 3.6 V VDD
RF Output Power Range -4   15 dBm
Filter insertion loss 1 2 3 dB
RF Sensitivity -148     dBm
RF Input Level     10 dBm
Frequency Range 862 868/915 1020 MHz
Frequency Accuracy   ±2   ppm
Communication Range   4.5 15 KM Depend on RF parameter
Transmit Current   43   mA RFOP = +15 dBm
Receive Current   16.5   mA AT+MODE=0
Sleep Current   0.5   uA AT+MODE=1
Baud rate 300 115200 115200 bps 8, N, 1
Digital Input Level High 0.7*VDD   VDD V VIH
Digital Input Level Low 0   0.3*VDD V VIL
Digital Output Level High 0.9   VDD V VOH
Digital Output Level Low     0.1 V VOL
Cycling (erase / write)



EEPROM data memory

   300   K Cycles
Weight   7   g
Operating Temperature -40 25 +85 ˚C
