WF70-800480A2H#008-FC

TFT 7" 800x480, HDMI Interface, IC TFP401, 350cd/m², Capacitive touch panel with Free Board USB interface (GG, ILI2511 IC)

RECOMMENDED ONLY AS SPARE PARTS

For new projects please contact us at [email protected].



DESCRIPTION

7 inch supporting HDMI (Only DVI) signal TFT-LCD module with Projected Capacitive Touch Panel (PCAP); it’s made of WVGA 800x480 resolution. This display has a Capacitive Touch Screen overlay on TFT panel.

The module is built in with TFP401 Controller IC convert signal to support HDMI (Only DVI) signal interface. The supply voltage for LCM (VDD) is typical value 5V. It is featured with Glare surface glass, view direction 12 o'clock, gray scale inversion 6 o'clock.



DRAWING



SKU: WF70-800480A2H#008-FC
Brand: Winstar
Available: No
Be the first to review this product
Accessory Kit
Price Breaks
Quantity
1+
5+
10+
Price
€102.20
€92.00
€77.50

For quantities above 25 pcs pls send your enquiry to [email protected] or call +39 0332 1888005

€102.20 excl tax

RECOMMENDED ONLY AS SPARE PARTS

For new projects please contact us at [email protected].



DESCRIPTION

7 inch supporting HDMI (Only DVI) signal TFT-LCD module with Projected Capacitive Touch Panel (PCAP); it’s made of WVGA 800x480 resolution. This display has a Capacitive Touch Screen overlay on TFT panel.

The module is built in with TFP401 Controller IC convert signal to support HDMI (Only DVI) signal interface. The supply voltage for LCM (VDD) is typical value 5V. It is featured with Glare surface glass, view direction 12 o'clock, gray scale inversion 6 o'clock.



DRAWING



Products specifications
Brand Winstar
Size 7"
Resolution 800x480
Active Area (mm) 154.08x85.92
Color Full Color
Display Interface HDMI
View Angle TN
Frame No
Touch Panel Capacitive
O. Temperature (°C) -20~70
Display Connection HDMI Connector
Touch Panel IC Controller ILI2511
Preferred - Not Preferred Preferred
Download
Products specifications
Brand Winstar
Size 7"
Resolution 800x480
Active Area (mm) 154.08x85.92
Color Full Color
Display Interface HDMI
View Angle TN
Frame No
Touch Panel Capacitive
O. Temperature (°C) -20~70
Display Connection HDMI Connector
Touch Panel IC Controller ILI2511
Preferred - Not Preferred Preferred
