In Professional Audio equipment, the display is the primary interface between the operator and the device. It must provide immediate readability of levels, routing, presets, EQ curves, DSP parameters, and system status, even during quick setup, sound checks, and live operation.
First Components offers a selection of compact, wide, and bar-type Winstar TFT displays designed for integration into:
🔸 DSP, equalizers, and signal processors
🔸 Digital mixers and audio matrices
🔸 Power amplifiers
🔸 Control and monitoring systems
Mechanical integration is particularly important in rack-mounted equipment. A standard 1U front panel has a nominal height of only 44.45 mm. Bar-type displays make the most of the available horizontal space, allowing multichannel meters, menus, and operating information to be displayed efficiently. In 2U to 4U rack systems, larger displays can be adopted to support more sophisticated graphical user interfaces.
Optical Performance and Integration Flexibility
Selecting the right display requires careful consideration of size, aspect ratio, active area, resolution, contrast, and viewing angle.
IPS panels ensure consistent readability even when equipment is installed in the upper or lower sections of a rack. Anti-Glare (AG) and Anti-Reflection (AR) surface treatments minimize reflections in control rooms and FOH (Front of House) environments, while Deep Black cover glass provides seamless integration with the dark front panels typically found on professional audio equipment by concealing the inactive display area.
Alongside conventional bar-type formats, round TFT displays offer a distinctive solution for rotary controls, encoders, and compact user interfaces, enabling levels, values, presets, and function status to be displayed directly around the control knob.
The Winstar product range also provides multiple interface options to match different hardware architectures:
🔸 SPI for compact microcontroller-driven displays
🔸 RGB and MIPI DSI for MCUs and MPUs with graphics controllers
🔸 LVDS and eDP for higher-resolution panels
🔸 HDMI for Single Board Computers and embedded platforms
Connectors, FPCs and cable assemblies can be customized to suit the electronic layout and EMC requirements, which are especially critical in equipment integrating sensitive analog audio circuitry.
At FIRST Components, we offer a complete portfolio of TFT displays ranging from 0.96" to 7", including both round and bar-type formats. We also provide comprehensive technical support to help you select the most suitable display and define any customizations required for seamless integration into your final product.
Find the Ideal Display for Your Application
For further technical information, please contact us at [email protected].
To receive a dedicated quotation for your project, please contact our sales team
at [email protected].
