COG graphic LCD module made of resolution 320x240 pixels. It is built-in with 2 chips of UCi7701 driver IC and 1 chip of UCi7702 driver IC; it supports 6800 and 8080 parallel interface, 1/240 driving duty. Furthermore, it is also built-in with negative voltage generator and temperature compensation available as optional.
This model supports 3.3V and 5V power supply voltage. This module can be operated at temperatures from -20°C to +70°C; its storage temperatures range from -30°C to +80°C. It is available in white background color and black content; the LCD matrix is a positive FSTN with transflective polarizer. Welcome to contact us if you need different LCD type and LED combination.
