RYUW122

UWB Antenna Transceiver Module, UART Interface 6.5 GHz and 8 GHz

Description

REYAX RYUW122 is designed as smart algorithm and high quality UWB(Ultra Wide Band) module, It is good for secure and precise distance measurement.

Item	Min.	Typical	Max.	Unit	Condition
VDD Power Supply	2.4	3.3	3.6	V	VDD
RF Output Power Range			-32	dBm
RF Sensitivity		-100		dBm
RF Input Level			14	dBm
Frequency Range		6489.6 7987.2		GHz	Channel 5 Channel 9
Bandwidth		850 6.8		KHz MHz
Location Accuracy		10		cm	Open Field Environment
Frequency Accuracy		±10		ppm
Communication Range		60		M	Open Field Environment
ANCHOR mode Current		8		mA
TAG mode Current		81		mA
RF Transmit Current		86		mA
RF disable Current		4		uA
Sleep Mode Current		2		uA
Baud rate	9600	115200	115200	bps	8, N, 1
Digital Input Level High	0.7*VDD		VDD	V	VIH
Digital Input Level Low	0		0.3*VDD	V	VIL
Digital Output Level High	0.9		VDD	V	VOH
Digital Output Level Low			0.1	V	VOL
Cycling (erase / write) Flash data memory		100		K	Cycles
Weight		1		g
Operating Temperature	-40	25	+85	˚C

SKU: RYUW122

Brand: Reyax

Disponibile: Si

Prezzi per quantità

Quantità

Prezzo

€22,40

€20,70

Per quantita’ maggiori di 25pz prego invii la richiesta a sales@first-components.com o chiami il +39 0332 1888005

€22,40 IVA esclusa
