Cover Lens Thickness Options for Winstar 7" TFT Displays
For industrial applications, thick cover lenses provide extra protection for TFT Displays. Putting hardened cover lens on the TFT module can protect it from mechanical damages. Winstar provides three kinds of thickness options for our 7 inch TFT-LCD modules which are including 0.7mm, 1.8mm and 3.0mm in thickness.
Below is a comparison chart for reference, the higher IK code which means for better impact protection. The IK Code, or impact rating, is an international numeric classification for the degrees of protection provided by enclosures for electrical equipment against external mechanical impacts. We recommend customers can choose proper thickness of cover lens for your applications. Winstar also can offer custom solutions for customers needing thick cover lens. Please note, the thickness of cover lens will affect the touch sensitivity; the thinner cover lens usually the touch sensitivity will be better than thicker ones.
Remark: Below information is reference only, welcome to contact our engineering team for different sizes of cover lens for applications.
|TP Part No.||Winstar 7"cover lens||Impact protection ||Detect points||Waterproof||Touch sensitivity|
||0.7 mm (standard)
Support TFT series: WF70G, WF70A2, WF70A7, WF70A8, WF70M, WF70P, WF70Q, WF70Y
